Nason TT-D1B-205R is a bimetal immersion temperature switch
Nason TT-D1B-205R is a bimetal immersion temperature switch
No reviews
Precio habitual
$83.20 USD
Precio habitual
Precio de oferta
$83.20 USD
Los gastos de envío se calculan en la pantalla de pago.
Cantidad
No se pudo cargar la disponibilidad de retiro
- Model (TT): Factory-set, bimetal immersion temperature switch using gold-diffused, fine silver contacts for reliable low-current electrical switching.
- Probe Length (D): Built with a short 1/2" probe length to fit compactly into shallow fluid paths.
- Media Connection (1): Standard 1/2" NPT male thread process connection.
- Circuit Form (B): SPST, Normally Closed (NC) circuit logic. The contacts stay closed during standard running conditions and open up when the temperature exceeds the limit.
- Fixed Set Point (205): Factory preset to actuate right at 205°F (96.1°C) with a standard manufacturing tolerance of ±5°F.
- Set Point Direction (R): Rising. The internal bimetal disc triggers the switch as system temperatures climb up to the 205°F set point.
