Lauderdale Speedometer & Compass
Nason HT-1C-200J/58 represents a shift from the pressure units discussed previously to a heavy-duty, bellows-actuated immersion temperature switch
Nason HT-1C-200J/58 represents a shift from the pressure units discussed previously to a heavy-duty, bellows-actuated immersion temperature switch
No reviews
Precio habitual
$198.65 USD
Precio habitual
Precio de oferta
$198.65 USD
Los gastos de envío se calculan en la pantalla de pago.
Cantidad
No se pudo cargar la disponibilidad de retiro
Core Technical Specifications
- Set Point Range Capability: 40°F to 300°F (HT Series threshold capability)
- Set Point Tolerance: ±5°F
- Switch Differential: 8°F to 16°F separation before resetting
- Maximum System Temperature: Up to 300°F (100°F max over set point)
- Electrical Contact Rating: 10 A @ 125/250 VAC or 5 A @ 30 VDC
- Maximum External System Pressure: 500 PSI
- Environmental Sealing: NEMA 4, NEMA 13 weather-proof housing [1, 2]
