Lauderdale Speedometer & Compass
VDO 382-152 Vision Black Series Electrical Power Trim Gauge
VDO 382-152 Vision Black Series Electrical Power Trim Gauge
No reviews
Normaler Preis
$55.67 USD
Normaler Preis
Verkaufspreis
$55.67 USD
Versand wird beim Checkout berechnet
Anzahl
Verfügbarkeit für Abholungen konnte nicht geladen werden
Core Technical Specifications
- Series: Vision Black
- Gauge Type: Electrical Power Trim Indicator (Down–Up Scale)
- Sender Compatibility: Calibrated for standard Mercury, Volvo Penta, and post-2001 Yamaha factory trim senders.
- Diameter Size: Standard 2-1/16 inches (52mm panel cutout).
- Operating Voltage: 12V DC.
- Electrical Connection: .250" Male spade terminals.
- Vision Aesthetics: High-contrast flat matte black dial face, a matching sleek black bezel, sharp white graphics, and an illuminated translucent red pointer needle.
- Advanced Mounting: Employs VDO's patented Spin-Lok™ mounting hardware. This spin-on clamp ring locks the housing with 360 degrees of uniform pressure, preventing panel warping and keeping the gauge from shifting during rough wake.
- Environmental Build: Features a single glass lens housing with an IP64 water and dust-resistance rating to reliably handle open-cockpit marine exposure. [1, 2, 3, 4, 5]
